AN-microSDH-E1-V35

One of the smallest in size on earth SDH device from AN-microSDH series. AN-microSDH-E1-V35 is micro sized SDH unit with 1 E1 & 1 V.35 unit over STM-1 interface.

  • Half 19”, 1 U box with standard STM-1 optical interfaces
  • 1 E1 and and 1 framed V.35 interface, standard SDH mapping.
  • E1 port complies with ITU-T G .703, with error monitor and loop back test functions
  • V.35 port complies with ITU-T V.35, with alarm monitor and loop back test function.
  • Various alarm indicators.
  • Inter-work with any SDH/MSPP products of various vendors with standard STM-1 optical interfaces.
  • Support agent network management by AN-MSPP,AN-miniSDH saving IP address.
  • High integration, compact design, can be hanged on the wall.
  • SDH/MSPP units at PDH price.
Items Description
Models

AN-microSDH-E1-V35

 1 STM-1 optical interface, 1 E1, 1 V.35
AN-microSDH-E1 1 STM-1 optical interface, 1 E1

AN-microSDH-V35

 1 STM-1 optical interface, 1 V.35
STM-1 optical interface Connector SC/PC
Spec. S-1.1, L-1.1, L-1.2

Single fiber bi-directional WDM interface can be optionally supported
Service interface E1 Spec.

Comply with G.703, 2.048Mbps, HDB3

75Ω unframed
V.35 port

Comply with ITU-T V.35/V.36 DCE or DTE, framed or unframed

2.048Mbit/s, n x 64kbps, where n = 1 …32
Physical Dimension H×D×W 44 mm ´136 mm ´ 220mm
Power Supply 220V (110V) AC or -48V DC
Consumption ≤8 w
Environment Temperature 0°C 45°C
Humidity 0-90%RH non-condensing


AN-microSDH-E1-V35/AC

AN-microSDH-E1-V35, 1 STM-1 optical interface, 1 E1, 1 V.35, AC power
AN-microSDH-E1-V35/DC

AN-microSDH-E1-V35, 1 STM-1 optical interface, 1 E1, 1 V.35, DC power

Description

One of the smallest in size on earth SDH device from AN-microSDH series. AN-microSDH-E1-V35 is micro sized SDH unit with 1 E1 & 1 V.35 unit over STM-1 interface. Working together with aggregation devices such as AN-miniSDH or AN-MSPP, they can support point to multi-point topology. They also support point to point network or working together with any SDH devices with standard STM-1 interfaces.

They also support point to point network or working together with any SDH devices with standard STM-1 interfaces.
