10/100/1000 Multirate Multimode to Single mode converter

AN-MM-SM series equipment can be used for Fast/Gigabit Single mode to Multimode conversions. Available in all type distances and fiber types, including the WDM



  • Supporting single fiber by double directions transmission;
  • According to any agreement between different dates.
  • Fulfilling medium convert between single-mode fiber and multi-mode fiber or extending fiber transmission distance, the wave length may be 850nm、1310nm or 1550nm.
  • Supporting medium convert between 100M fast speed Ethernet, 1000M Ethernet, or extending transmission distance.
  • The longest transmission distance of multi-mode is 2KM; The longest transmission distance of single-mode is 120KM.
  • WDM single fiber versions are available
  • As optical receiving and sending model with good optical character, electrical character, date transmits steady, and it can work for long time..
  • The transmission of optical mode 155M is above 30db and optical mode 1.25G is above 25db.
  • As it is manufactured by assembly line with advanced jointing, model works steady ,date transmits stably, and its anti – interference is outstanding.
  • optical fiber interface: SC
  • optical fiber type
    Multi-mode : 50/125um, 62.5/125um,100/140um,wave length:850 or 1310nm
    Single-mode: 8.3/125um,8.7/125um,9/125um,10/125um,wave length :1310 or 1550nm
  • Transmission distance: multi-model with 2KM, single-model with 120KM.
  • Transmission rate: 10/100Mbps、155Mbps、622 Mbps、1000 Mbps、1.25Gbps、2.5Gbps
  • Indicator light: it indicates power supply’s condition , also suggests single-fiber and        multi-fiber link condition.
  • Power supply: absolute construction: 1)input 100v~260VAC 2)input 36V-72VDC , output 3W.
  • Power:<3W.
  • Size: 26mm(H)*70mm(W)*90mm(D)
  • Work temperature :0℃~50℃
  • Storage temperature: -20℃~80℃
  • Humidy:5%~90% without condensing
AN-MM-SM-G10/550

10/100/1000M, MM dual fiber to SM dual fiber，internal power supply，SM 10Km，MM 850nm 550M
AN-MM-SM-G10/1310

10/100/1000M, MM dual fiber to SM dual fiber，internal power supply，SM 10Km ,MM 1310nm、550m
AN-MM-SM-G20/850

10/100/1000M, MM dual fiber to SM dual fiber，internal power supply, SM 20Km，MM850nm，550m
AN-MM-SM-G20/1310

10/100/1000M, MM dual fiber to SM dual fiber，internal power supply，SM 20Km，MM 1310nm，550m
AN-MM-SM-G40/850

10/100/1000M, MM dual fiber to SM dual fiber，internal power supply，SM 40Km，MM 850nm，550M
AN-MM-SM-G60/850

10/100/1000M, MM dual fiber to SM dual fiber，internal power supply，SM 60Km，MM 850nm，550M
AN-MM-SM-G70/850

10/100/1000M, MM dual fiber to SM dual fiber，internal power supply，SM 70Km，MM 850nm，550M
AN-MM-SM-G80/850

10/100/1000M, MM dual fiber to SM dual fiber，internal power supply，SM 80Km，MM 850nm，550M

Description

AN-MM-SM series equipment can be used for Fast/Gigabit Single mode to Multimode conversions. Available in all type distances and fiber types, including the WDM.
It is to fulfill optical signal transparent transmission through medium between single-mode fiber and multi-mode fiber, or it can also extend single-mode transmission distance, according to any agreement between different dates.
