	8 Voice (FXS/FXO) POTS fiber multiplexer, Ethernet & E1, serial ports as options

	AN-FM-PCM08 fiber mux is an optical transmission equipment realizing long-distance voice transmission through fiber. Primary interfaces are 8 x FXS/FXO voice but additional E1, Ethernet or E1 can be added upon request

This equipment uses design of ultra large scale integrated circuit, and its outward appearance is succinct. The merits include easy installation and debugging, unnecessary for maintenance and steady performance. It is suitable in business for communication operator, government and kinds of entities.

AN-FM-PCM16 fiber mux can provide 1-8 channels, telephone through optical cable, the network application is point-to-point, supporting FXO/FXS. It has solved telephone transmission problem of edge customers. This equipment uses special digital multiple-connected chip whose function is formidable, and it integrates nearly all the digital logical function of equipment, thus remarkably enhancing product performance and reducing cost.

Additional channels of E1, Ethernet and RS-232 can be added upon request

Low cost solution for delivering analogue POTS lines over long distance fibers;
up to 8 FXO ports for connection to PABX or PSTN;
up to 8 FXS ports for connection of phones or faxes;
Ethernet port for LAN interconnection;
RS-232 for data transmission
Up to 4E1 ports as an option for PABX interconnection or any other E1 Leased lines services
MTBF more than 10 years
WDM Bidi fiber interfaces avalaible

FXS
ringing voltage: 75V
ringing frequency: 25HZ

FXO
two line input impedance: 600 Omega (hanging off)
wastage: 40 db
ringing detecting voltage: 35V

Optical Interface Parameter
optical wavelength: 850nm/1310nm for multi-mode optical interface, 1310nm/1550nm for single-mode optical interface
optical interface: SC/FC
receiving and dispatching module: >-6dBm
optical receiver receiving sensitivity <-36 (BER<10):
dynamic receiving range: >-30dB
transmitting range: Multi-mode 2 Km, single-mode 40Km, single-mode 60 Km, single-mode 120Km, WDM bidi available
vibration characteristic: Comforms G.742 and G.832 standard

Features Slideshow:

AN-FM-PCM08 Request price	8 channels voice on fiber, SC/FC connector, FP1310nm,single fiber 20km, voice interface supports FXO or FXS, AC110/220V or DC-48V;
AN-FM-PCM08/4E1/ETH Request price	8 channels voice on fiber, SC/FC connector, FP1310nm,single fiber 20km, voice interface supports FXO or FXS, Ethernet port(10/100 M adapt), 4E1 port (E1 support 75ohm or 120ohm), AC110/220V or DC-48V;
AN-FM-PCM08/4E1/ETH/RS-232 Request price	16 channels voice on fiber, SC/FC connector, FP1310nm,single fiber 20km, voice interface supports FXO or FXS, Ethernet port(10/100 M adapt), 4E1 port (E1 support 75ohm or 120ohm), and RS232 port AC110/220V or DC-48V;
